Dialyzer
Hemodialysis is a method for removing waste products such as creatinine and urea, as well as free water from the blood when the kidneys are in kidney failure. The mechanical device used to clean the patients blood is called a dialyser, also known as an artificial kidney. Modern dialysers typically consist of a cylindrical rigid casing enclosing hollow fibers cast or extruded from a polymer or copolymer, which is usually a proprietary formulation. The combined area of the hollow fibers is typically between 1-2 square meters. Intensive research has been conducted by many groups to optimize blood and dialysate flows within the dialyser, in order to achieve efficient transfer of wastes from blood to dialysate.
FEATURES
Use the semi permeable characteristics of dialysis membrane and the physical principles of dispersion, ultrafiltration and convection to remove harmful substances and excessive water in blood;
The blood import and export, dialysate import and export of this product are fully formulated in accordance with international standards and corresponding industrial standards, and can be used together with dialysis machines and pipelines in the United States, Japan, Germany, Sweden and China.
SPECIFICATIONS
Single units: Kits packed in blister with paper.
Secondary packaging: Single layer corrugated paper.
Tertiary packaging: Double walled corrugated board.
| Â | Number of pieces | Dimensions |
| Shipping Carton | 24 | 46*34*34CM |
| Specification and Model | A-40 | A-60 | A-80 | A-200 |
| Fibrous membrane area(m2) | 1,4 | 1,6 | 1,8 | 2 |
| Blood flow rate (ml/min) | 200-400 | 200-400 | 200-400 | 200-400 |
| Inner diameter of fibrous membrane (μm) | 200 | 200 | 200 | 200 |
| Fiber membrane wall thickness (μm) | 40 | 40 | 40 | 40 |
| Blood ventricular volume (mL) | 78 | 86 | 99 | 108 |
| Maximum transmembrane pressure (mmHg) | 500 | 500 | 500 | 500 |
